D7-175KL/190KL

product

D7-175KL/190KL

Ready to conquer any terrain with the D79-190KL Hub Motor?

High-Power Rear E-Bike Hub Motor

Tailored for Fat Tire Electric Bicycles

Customizable Power up to 2000W

Achieves a Maximum Torque of 110N.m

O.L.D is 190mm, Cassette Freewheel

Redefine Your E-Bike Experience Today!

350 – 750

Rated Power

90 N·m

Torque

175 / 190

O.L.D

DISCOVER THE E-BIKE D79-190KL HUB MOTOR!

High Power Rear E-Bike D79-190KL Hub Motor: Your gateway to electrifying e-bike adventures.

Tailored for Fat Tire Electric Bicycles: Specially designed for fat tire e-bikes with customizable power from 1000W to an exhilarating 2000W and a maximum torque of 110N.m.

Built to Endure: Crafted from aluminum alloys for high resistance to humidity, rust, corrosion, dust, and environmental elements.

Lightweight and Low Maintenance: Enjoy a durable, featherweight design with minimal upkeep.

Whisper-Quiet Performance: The high-power motor ensures a silent, quick start and robust climbing ability.

Easy Installation: High efficiency, minimal noise, and rapid response.

Get in Touch With Us Now!

Sensor Type

Rear

O.L.D (open size)

175 / 190

Drive Train

8 – 10 speed

Voltage

36 / 48 / 52 / 60 v

Rated Power

350 – 750

Peak Torque

90 N·m

Net Weight

4.1 kg

Wheel Size

20 / 26 / 28 / 700C

Gear Ratio

7.77 : 1

Dropout Width

175 / 190

hub-motor

Application Type

eCargo / eFat

Noise Level (dB)

< 60

Operating Temperature (℃)

-20 to 45

Connector Type

Waterproof Plug

Cable Lenghth (mm)

Customized

IP Rating

IP 65

Certifications

CE/RoHS/EN 15194
